Dryer FIV Premium quality system for drying of photopol


Premium quality system for drying of photopolymer flexo printing plates

Compare

Benefits

Excellent productivity and consistency

  • Uniform temperature distribution through the separate drying chambers
  • Touch screen displays all necessary times and settings and offers maintenance diagnostics
  • Highly efficient exhaust air extraction system with safety shut-down facility prevents solvent vapours from escaping during drying
  • High-powered heating output to quickly achieve the necessary operating temperature
  • Excellent build quality offers a long service life

Ecologically friendly and economical

  • Two chamber design with individual temperature control for energy saving and efficiency
  • Low energy consumption due to good heat insulation
  • Surface temperature of the heating elements can be adapted to solvent type

Easy and comfortable handling

  • Easy to operate via display
  • Six drying drawers with wide opening and mechanical support of drawer opening and closing
  • Programmable digital timer and count down facility for each drying drawer
  • Audio alarm to signal end of drying time
  • Automatic shut down is possible
  • Additional air extraction when opening the dryer drawers prevents the escape of solvent vapors in the work area
Maximum plate size (W x L)

1250 mm x 1600 mm (49.2" x 63.0")

Electrical connection

230 V/ 50/60 Hz (3 Ph/PE)

Nominal current

24.1 A / 13.5 A

Nominal power

8.8 kW

Exhaust air flow rate

min. 450 Nm³/h (265 CFM) NW 160 mm (6.3")

Weight (approx.) net

900 kg (1985 lbs)

Weight (approx.) gross

1366 kg (3012 lbs)

Crate dimensions (W x D x H)

2620 mm x 2260 mm x 1495 mm (103.2" x 89.0" x 58.9")
